ALPINE CDE-121 68-16909Z79-A (EN)
Playback
1
Insert a disc with the label side facing up.
The disc will be pulled into the unit automatically, and the
“ ” indicator lights up.
When a disc is already inserted, press SOURCE/ to
switch to the DISC mode.
The mode will change every time the button is pressed.
TUNER DISC USB AUDIO/iPod*
1
AUX*
2
TUNER
*
1
Displayed only when the iPod/iPhone is connected.
*
2
Refer to “Using the Front AUX Input Terminal”
(page 16).
2
While playing back MP3/WMA/AAC, press 1
or 2 to select the desired folder.
Pressing and holding 1 or 2 will change folders
continuously.
3
Press or to select the desired track
(file).
Returning to the beginning of the current track (file):
Press .
Fast backward:
Press and hold .
Advancing to the beginning of the next track (file):
Press .
Fast forward:
Press and hold .
4
To pause playback, press //ENT.
Pressing //ENT again will resume playback.
5
To eject the disc, press .
• Do not remove a CD during its eject cycle. Do not load
more than one disc at a time. A malfunction may result
from doing either.
• If the CD does not eject, press and hold for at least 2
seconds.
• The “ ” indicator lights up when a disc is inserted.
• Three-inch (8 cm) CDs cannot be used.
• The CD-player can play discs containing audio data,
MP3 data, WMA data and AAC data.
• WMA format files that are protected by DRM (Digital
Rights Management), AAC format files that have been
purchased from the iTunes Store and files that are copy-
protected (copyright protection) cannot be played back
on this unit.
• The track display for MP3/WMA/AAC data playback is
the file numbers recorded on the disc.
• The playback time may not be correctly displayed when
a VBR (Variable Bit Rate) recorded file is played back.
MP3/WMA/AAC Play Display
The folder number and file number will be displayed as
described below.
• Press VIEW to switch the display. See “Displaying the
Text” (page 15) for information about display switching.
CD/MP3/WMA/AAC
4
5
VIEW
SOURCE/
j/r/ENT
Rotary encoder
/ESC
/MUTE
2
1
F101 T103
Folder number
display
File number
display
01GB00CDE121.book Page 10 Monday, December 13, 2010 2:03 PM
