Jensen CD3720XM Car Stereo System User Manual



RELEASE
/
CAT
AUX IN
CD3720XM
MOSFETPOWER
AS/PS
MODE
EQ
MUTE
MON
DX/XM
CDRECEIVER
XM-FUNC
DISP
BND/LOU
CH
Remove transport screws
Quite los tornillos transportadores
Enlevez les vis de transport
Remove half sleeve
Quite la media camisa
Enlevez le demi-fourreau
2
1
L
O
C
M
U
T
MO
N
CDRECEIVER
PAU
SCN
RP
T
S
H
F
S
C
N
B
ND
/
LO
U
D
SP
A
M
S
M
OD
E
Q
DIM
S
W
R
X
CD3720XM
Owner’s Manual
Thank You!
Thank you for choosing a Jensen product. We hope you will find the instructions in this
owner’s manual clear and easy to follow. If you take a few minutes to look through it, you’ll
learn how to use all the features of your new Jensen receiver for maximum enjoyment.
Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Tuner Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
XM Radio Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
CD Player Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Preparation
Getting Started
It’s a good idea to read all of the instructions before beginning the installation.
Tools and Supplies
The following tools and supplies are needed to install the radio.
Torx type, flat-head and Philips screwdrivers
Wire cutters and strippers
Tools to remove existing radio (screwdriver, socket wrench set or other tools)
Electrical tape
Crimping tool
Volt meter/test light
Crimp connectors
18 gauge wire for power connections
16 – 18 gauge speaker wire
Speaker Requirements: Only connect speakers rated with the load impedance of 4 ohms.
Speakers with a load impedance of less than 4 ohms could damage the unit.
Disconnect Battery
Before you begin, always disconnect the battery negative terminal.
Prepare Radio
1. Remove the half sleeve – Press the metal levers on both sides to remove the half-sleeve
from the radio.
2. Remove transport screws
– Remove transport screws before inserting a CD.
