Kole Audio KLE Woofers
Congratulations on your purchase of one of the finest woofers available for your vehicle today.
Adding affordable bass to your system was never easier with Kole Audio’s KLE Series woofers. Kole
Audio’s engineers used the combination of a Polypolne cone and a rubber progressively slanted surround to
give you dependable affordability in a woofer that can be used in a sealed or ported enclosure.
Please take a few moments to fill out the warranty card and review this manual before installing this woofer
for proper connections and box sizes.
Heavy-Gauge, Specially Designed Steel Baskets
Blue Polypolne Cones w/Raised Conical Dust Caps
Progressively Slanted Butyl Rubber Surround
Single 4-ohm, 4-Layer Kapton Voice Coils
Black Spider
Chrome Front & Back Plates
Rubber Magnet Cover
Chrome Push Terminals
SPL: 10” – 91 dB 12” – 92 dB
Magnet size: 10”- 55oz. 12” – 60oz.
Voice Coil sizel: 10” – 2.0” 12” – 2.0”
RMS Power (watts): 10” –250 12” – 300
MAX Power (watts): 10” – 500 12”- 600
KLE-10
KLE-12
Fs 31.3 Hz 31.9 Hz
Vas 1.05 Cu. Ft. 1.86 Cu. Ft.
Qms 5.235 2.97
Qes 0.472 0.638
Qts 0.4325 0.525
Xmax 0.315” 0.315”
Design Features
Thiele / Small Parameters
