SPECIFICATIONS
NOTE: Design and specifications are subject to change without prior notice. Dimensions and weight are approximate.
Camera
Optics
Functions
Interfaces
PC interface
Lighting
Others
Image pick-up device
Effective pixels
Frame rate
Resolution RGB output
Video output
Zoom
Lens
Shooting area
Focus
White balance
Nega/Posi conversion
Frame Accumulate Mode
Edge enhancement
Color/B&W selection
Pause mode
Digital zoom
Gamma adjustment
OSD (on-screen display)
Image save
Image rotation
Down converter
Internal selection
Analog RGB output
Video output
DC 12V output
RGB input
Mouse port
RS-232C port
USB port
Upper lighting unit
Base light
Accessories
Dimensions Setup
(W x D x H) Folded
Weight
Application software
Power source
1/3" progressive scan CCD, 850,000 pixels
1034 (H) x 779 (V)
20 frames/sec.
600(H) x 600(V) TV lines
400(H) TV lines
Powered ( with double speed function ), 18x Optical
F2.8, f=4.7 to 84.6mm
Max. 13 7/8" x 10 1/4" ( 350 x 260mm )
Min. 1 1/8" x 7/8" ( 30 x 23mm )
Auto/Manual (powered)
Full-Auto/One-Push/Manual
Provided
Provided
Provided
Provided
Provided
Provided (2x, Scroll)
Provided
Provided
Internal ( x 8 )
Provided ( 0°, 90°, 180°, 270°)
Provided
Int./RGB1/RGB2
XGA (1024 x 768 @60Hz)
Composite, S-Video
Provided
Provided ( x2 )
Provided
Provided
Provided
Provided ( twin fluorescent lamp )
Provided
AC adapter, RGB cable, LCD monitor connection cable
Video cable, S-Video cable, USB cable, Instruction manual
IR remote control, Mouse, Utility software CD-ROM, Warranty card
27 1/2" x 21 3/8" x 21 7/8" ( 697 x 542 x 555mm )
15 3/4" x 21 3/8" x 7 1/8" ( 400 x 542 x 181mm )
21.6lbs (9.8Kg)
Image Mate
TWAIN drive ( for Windows, Mac )
AC 100 to 240V, 50/60Hz
High-Resolution Visual Presenter HV-5100XG
PROFILE
Printed in Japan(A)12/2007
21 3/8 21 7/8 21 3/8
15 3/4
27 1/2
15 3/4
All dimensions in inches(mm)
HV-5100XG
High-Resolution Visual Presenter
18times
Optical Zoom
850,000 pixels
Progressive
Scan CCD
Moving Picture
Output 20
frames / sec.
F.A.M.
(Frame Accumulate Mode)
