4–18 Getting Started
Notebook Features
Right-Side Components
Refer to the illustration that most closely matches your notebook.
Component Description
1
Audio-out (headphone) jack Produces system sound when
connected to optional powered stereo
speakers, headphones, headset, or
television audio.
2
Audio-in (microphone) jack Connects an optional stereo or
monaural microphone.
3
USB ports (2) Connect USB 1.1- and 2.0-compliant
devices to the notebook using a
standard USB cable, or connect an
optional External MultiBay II to the
notebook. The MultiBay II must also be
connected to an external power
source.
4
Optical drive
(select models only)
Reads an optical disc.
5
Optical drive button
(select models only)
Releases the media tray.
6
Serial port Connect an optional serial device.
