23-EN
01GB05CDA9883E.fm
ALPINE CDA-9883E 68-08564Z12-A (EN)
Band Button
Radio mode: BAND Button
Press this button and the band will change.
Changer mode: To switch the changer.
UP Button
Radio mode: SEEK (UP) button
CD/iPod mode: Press this button to advance to the
beginning of the next track.
Button
Radio mode: Pressing this button will select, in descending
order, stations programmed into the radio’s presets as
shown below.
...
CD Changer mode: DISC Select (DN) button
Press this button to select a disc in descending order.
MP3/WMA/AAC mode: Folder Select (DN) button
Press this button to select the folder.
MP3 compatible CD changer mode:
Folder Select (DN) / DISC Select (DN) button
Press this button to select a folder in descending order.
Press and hold this button to select a disc in descending
order.
iPod mode: Switches Playlist/Artist/Album.
Mute Button
Press this button to lower the volume by 20 dB instantly.
Press this button again to cancel.
Battery Replacement
Applicable battery: Use two “AAA” sized dry batteries or equivalent.
1
Opening the battery cover
Slide out the battery cover while firmly pressing in the
direction of the arrow.
2
Replacing the battery
Insert the batteries, observing the polarities as illustrated.
3
Closing the cover
Slide the cover as illustrated until a click is heard.
Controllable With Remote Control
Point the remote control transmitter at the remote control
sensor.
Connectable to Remote Control Interface Box
This unit may be controlled from the vehicle’s audio controls.
An optional Alpine Remote Control Interface Box must be
used. For details, contact your Alpine dealer.
Remote control sensor
