Alpine CDE-9882RI Car Stereo System User Manual



26-EN
Specifications
FM TUNER SECTION
MW TUNER SECTION
LW TUNER SECTION
CD PLAYER SECTION
PICKUP
USB SECTION
GENERAL
CHASSIS SIZE
NOSEPIECE SIZE
Due to continuous product improvement, specifications and design
are subject to change without notice.
CAUTION
Tuning Range 87.5-108.0 MHz
Mono Usable Sensitivity 0.7 µV
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
Tuning Range 531-1,602 kHz
Sensitivity (IEC Standard) 25.1 µV/28 dB
Tuning Range 153-281 kHz
Sensitivity (IEC Standard) 31.6 µV/30 dB
Frequency Response 5-20,000 Hz (±1 dB)
Wow & Flutter (% WRMS) Below measurable limits
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
Wave length 795 nm
Laser power CLASS I
USB requirements USB 1.1/2.0
Max. Power Consumption 500 mA
USB Class Mass Storage
File System FAT 12/16/32
MP3 Decoding MPEG-1/2 AUDIO Layer-3
WMA Decoding Windows Media™ Audio
AAC Decoding AAC-LC format “.m4a” file
Number of Channels 2-Channel (Stereo)
Frequency Response* 5-20,000 Hz (±1 dB)
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
* Frequency response may differ depending on the encoder
software/bit rate.
Power Requirement 14.4 V DC
(11-16 V allowable)
Maximum Power Output 50 W × 4
Maximum Pre-Output Voltage 2 V/10 k ohms
Bass ±14 dB at 60 Hz
Treble ±14 dB at 10 kHz
Weight 1.5 kg (3 lbs. 4 oz)
Width 178 mm (7")
Height 50 mm (2")
Depth 160 mm (6-1/4")
Width 170 mm (6-3/4")
Height 46 mm (1-13/16")
Depth 24 mm (15/16")
CLASS 1
LASER PRODUCT
(Bottom side of player)
