4-EN
5 Install the rear interchangeable color cover.
Align the openings on the cover with the rear button panel.
Press down firmly to snap the cover into place.
Ensure that all notches have gone into their grooves
properly.
Removing Interchangeable Color Cover
1 Remove the rear interchangeable color cover.
Reach across the monitor body and grasp the rear panel.
Gently lift the panel until it snaps off from the body
2 Remove both side panels of the interchangeable
color covers.
Grasp side cover as illustrated.
Raise the corner touching the rear control panel a few
millimeters and gently slide the cover out.
Do not immediately lift the cover before sliding it. The
notches will be damaged.
A small flat screwdriver or similar tool can be used to raise the
corner of the panel.
3 Remove the top interchangeable color cover.
Exercise caution when removing the top plate.
- The LCD screen must be closed during removal.
- Begin removal from the rear of the panel (side facing the
3 button panel).
- Removal by hand or by using soft tools is recommended
as hard tools may scratch the panel surface.
- Grasp the cover by the indentations and pull gently until
the cover snaps off from the LCD screen.
