AOC 916Swa Car Video System User Manual



DCR Demos:
Disclaimer: DCR aftereffects are subject to the resolution and quality of the display content, hence may look different than the above illustrations.
Function Control Illustration
Luminance Adjust Range Description
Brightness 0-100 Backlight Adjustment
Contrast 0-100 Contrast from Digital-register.
Standard Standard Mode
Text Text Mode
Internet Internet Mode
Game Game Mode
Movie Movie Mode
Eco mode
Sports Sports Mode
Gamma1 Adjust to Gamma1
Gamma2 Adjust to Gamma 2
Gamma
Gamma3 Adjust to Gamma 3
Off Disable dynamic contrast ratio
DCR
On Enable dynamic contrast ratio
Image Setup
Clock 0-100 Adjust picture Clock to reduce Vertical-Line noise.
Focus 0-100 Adjust Picture Phase to reduce Horizontal-Line noise
H.Position 0-100 Adjust the verticalposition of the picture.
V.Position 0-100 Adjust the horizontal position of the picture.
Color Temp.
Warm
Recall Warm Color Temperature from EEPROM.
Normal
Recall Normal Color Temperature from EEPROM.
Cool
Recall Cool Color Temperature from EEPROM.
sRGB
Recall SRGB Color Temperature from EEPROM.
User User-B Blue Gain from Digital-register
