Specification
General Specification
Model number
Driving system TFT Color LED
Viewable Image Size 50.8cm diagoanl
Pixel pitch 0.2766mm(H) x 0.2766mm(V)
Video R, G, B Analog lnterface
Separate Sync. H/V TTL
Display Color 16.7M Colors
Panel
Dot Clock 108 MHz
Horizontal scan range 30 kHz - 83 kHz
Horizontal scan Size(Maximum) 442.8mm
Vertical scan range 55 Hz - 75 Hz
Vertical scan Size(Maximum) 249.075mm
Optimal preset resolution 1600 x 900 (60 Hz)
Highest preset resolution 1600 x 900 (60 Hz)
Plug & Play VESA DDC2B/CI
Input Connector D-Sub 15pin
Input Video Signal Analog: 0.7Vp-p(standard), 75 OHM,
Power Source 100~240VAC, 50/60Hz
Active < 20 W (Typical)
Resolution
Power Consumption
Standby < 0.5 W
Connector Type 15-pin Mini D-Sub
Signal Cable Type Detachable
Dimensions & Weight:
Height (with base)
367.4 mm
Width
480.8 mm
Depth
182 mm
Physical
Characteristics
Weight (monitor only)
2.3 kg
Temperature:
Operating C to 40° C
Non-Operating -25°Cto 55°C
Humidity:
Operating 10% to 85% (non-condensing)
Environmental
Non-Operating 5% to 93% (non-condensing)
e2043Fs /e2043Fsk /e2043Fsb
