OWNER’S MANUAL
In extremely cold temperatures, the movement of the picture may be slow and
the picture may be dark, but this is not a malfunction. The set will work
normally once the temperature increases.
Small black and shiny dots inside the liquid crystal panel are normal for liquid
crystal product.
DESCRIPTION
The VMA7192 is a TFT active matrix color LCD monitor which delivers a striking
picture and superior image resolution. The VMA7192 can be used to enjoy video
images with the Clarion video sources, even if no TV tuner is connected.
P
ACKAGE CONTENTS
7" monitor
5m long cable with 4 male connectors (Video 1, Video 2, Power/Ground,
3.5mm IR)
Hardware (One 1/4-20 with nut and washer)
50cm 2 Pin Power cable
BUTT
ON AND CONNECTOR LOCA
TIONS
5
1
3
2
6
4
7
8
9
10
1 Power Button
2 IR Sensor
3 Picture Control Button
4Wide Mode (16:9/4:3 Format)
5 Source Button
(Video 1/Video 2 Select)
68 Pin DIN Pigtail
7Video 1 Input
8Video 2 Input
9 Power Connector
10 IR Remote Out
11 Picture Select Up
12 Picture Select Down
2
11
12
