SCB2001K
GE Profile Advantium
®
Wall Oven
Single
Speedcook Installation
Speedcook Oven Installation
above a single GE Built-In Wall Oven
Speedcook Oven Installation
above a GE Warming Drawer
36-3/4 Min.
Required
30
19
Min
Construct Solid
Bottom Min. 3/8"
Plywood
Supported by
2 x 4 or 1 x 2
Runners, all
Four Sides
28-1/2
21
530Dia3
36-3/4 Min.
530Dia13
30
24
Min.
Construct Solid
Bottom Min. 3/8"
Plywood
Supported by
2 x 4 or 1 x 2
Runners, all
Four Sides
2 Min.
Install
2 x 4 or 2 x 2
Runners or
Solid Bottom,
Must Support
100 lbs.
28-1/2
21
9-1/4
*45-1/
4
530Dia4
30
24
Min.
Construct Solid
Bottom Min. 3/8"
Plywood
Supported by
2 x 4 or 1 x 2
Runners, all
Four Sides
2 Min.
Per Oven
Requirement
28-1/2
21
240440
Specification Revised 2/07
Dimensions and Installation Information (in inches)
Order a 30” wide single oven cabinet or cut the
opening in a wall to dimensions shown.
Note: The rough opening must be:
• Depth – 19” Min.
• Width – 28-1/2” Min.
• Height – 21” Min.
• 36-3/4” from the floor to the cutout is required.
• These ovens require 3/4” overlap on each side,
top and bottom of the cutout.
• Oven overlaps will conceal cut edges on all sides
of the opening.
Note: For installation above a warming drawer
additional clearance between the two cutouts
may be required. Check to be sure the oven
supports above the Warming Drawer location
do not obstruct the required interior 23-1/2” depth
and 9-1/4” height.
Installation Information: Before installing, consult
installation instructions packed with product for
current dimensional data.
