User’s Manual
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
Size
LCD Panel
Pixel pitch 0.282mm(H) x 0.282mm(V)
H-Frequency 24KHz –83KHz
Video
V-Frequency 56 – 76Hz
Display Colors 16.7M Colors
Max. Resolution 1680 x 1050 @75Hz
Plug & Play
VESA DDC2B
TM
, DPMS
ON Mode ≤55W
Power Saving Mode ≤1 W
Power consumption
OFF Mode ≤1 W
Audio output Rated Power 2.0W rms (Per channel)
Input Terminal
VGA
DVI (Dual-Input Model)
Maximum Screen Size
Hor. : 473.8mm
Ver. : 296.1mm
Power Source 100~240VAC,50±3Hz,60±3Hz
Environmental
Considerations
Operating Temp: 0° to 40°C
Storage Temp.: -20° to 55°C
Operating Humidity: 20% to 80%
Dimensions
510 (W) x 423(H) x 223(D) mm
20 ”(W)×16.7 ”(H)×8.8 ”(D)
Weight (NW) 4.9kg (10.8 lb)
*** The above specification is subject to actual product specification and is subject to change
without prior notice.
NOTES:
The Maximum Resolution will depends on the display card supporting. Related issue can refer to
www.hannsg.com FAQ section.
23
56cm / 22” viewable
