Filter
Top Products
Panel
PanelPanel
Panel
Type
TypeType
Type
22-inch Wide-Aspect Active Matrix TFT (thin film transistor)
Viewable Image Area
Viewable Image AreaViewable Image Area
Viewable Image Area
22 in (55.9 cm) widescreen; diagonally measured
Screen Opening
Screen OpeningScreen Opening
Screen Opening
(W x H)
18.8 x 11.8 in (47.8 x 30.0 cm)
Panel Type
Panel TypePanel Type
Panel Type
TN
Aspect Ratio
Aspect RatioAspect Ratio
Aspect Ratio
16:10
Viewing Angle
Viewing AngleViewing Angle
Viewing Angle
(typical)
Up to 160° horizontal/160° vertical (10:1 minimum contrast ratio)
Brightness
BrightnessBrightness
Brightness
(typical)
*
250 nits (cd/m
2
)
Contrast Ratio
Contrast RatioContrast Ratio
Contrast Ratio
(typical)
*
1000:1
Dynamic Contrast Ratio
Dynamic Contrast RatioDynamic Contrast Ratio
Dynamic Contrast Ratio
(typical)
*
3000:1
Response Rate
Response RateResponse Rate
Response Rate
(typical)
*
5 ms (on/off)
Pixel Pitch
Pixel PitchPixel Pitch
Pixel Pitch
0.282 mm
Backlight Lamp Life
Backlight Lamp LifeBacklight Lamp Life
Backlight Lamp Life
(to half brightness)
50K hours
Color Gamut
Color GamutColor Gamut
Color Gamut
72% color gamut (NTSC,TYP)
*All performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
On Screen Display
On Screen DisplayOn Screen Display
On Screen Display
(OSD)
Controls
ControlsControls
Controls
Buttons or Switches
Buttons or SwitchesButtons or Switches
Buttons or Switches
OSD menu, OSD up, Source select/OSD down, Auto adjust/OK, Power.
(from left to right)
Languages
LanguagesLanguages
Languages
English, French, German, Spanish, Italian, Dutch, and Japanese, S. Chinese,
T.Chinese, Brazilian Portuguese
User Controls
User ControlsUser Controls
User Controls
Brightness, contrast, positioning, color temperature (6500k, 9300k, custom),
individual color control, serial number, display, clock, clock phase, monitor
management, factory reset
Signal Interface/
Signal Interface/Signal Interface/
Signal Interface/
Performance
PerformancePerformance
Performance
Horizontal Frequency
Horizontal FrequencyHorizontal Frequency
Horizontal Frequency
24 to 83 kHz
Vertical Frequency
Vertical FrequencyVertical Frequency
Vertical Frequency
50 to 76 Hz
Native Resolution
Native ResolutionNative Resolution
Native Resolution
1680 x 1050 @ 60 Hz (WSXGA+), 1.76 Million pixels
Preset VESA Graphic
Preset VESA GraphicPreset VESA Graphic
Preset VESA Graphic
Modes
ModesModes
Modes
(non-interlaced)
1680 x 1050 @ 60 Hz
1600 x 1200 @ 60 Hz
1600 x 1000 @ 60 Hz
1440 x 900 @ 60 Hz
1280 x 1024 @ 60 Hz
1280 x 960 @ 60 Hz
1024 x 768 @ 60 Hz
800 x 600 @ 60 Hz
640 x 480 @ 60 Hz
Text Mode
Text ModeText Mode
Text Mode
720 x 400 @ 70 Hz
Mac Mode
Mac ModeMac Mode
Mac Mode
Not supported
Sun Mode
Sun ModeSun Mode
Sun Mode
Not supported
Maximum Pixel Clock
Maximum Pixel ClockMaximum Pixel Clock
Maximum Pixel Clock
Speed
SpeedSpeed
Speed
165 MHz (analog input); 165 MHz (DVI input), 230 Mhz (DisplayPort)
QuickSpecs
HP Compaq LA2205wg 22-inch Widescreen LCD Monitor
HP Compaq LA2205wg 22-inch Widescreen LCD MonitorHP Compaq LA2205wg 22-inch Widescreen LCD Monitor
HP Compaq LA2205wg 22-inch Widescreen LCD Monitor
Technical Specifications
DA - 13443 North America — Version 3 — October 30, 2009
Page 2
