SPECIFICATIONS
1. Continuous 4W load 20Hz to 200Hz, < 0.05% THD, with input voltage at 13.8VDC.
2. Continuous 2W load 20Hz to 200Hz, < 0.1% THD, with input voltage at 13.8VDC.
Amplifier Section Orion 600D Orion 1200D Orion 2500D
Power Output 4W (Watts)1 250 x 1 425 x 1 1200 x 1
Power Output 2W (Watts)2 400 x 1 725 x 1 1700 x 1
Power Output 1W (Watts) 600 x 1 1200 x 1 2500 x 1
Externally Bridgeable Yes Yes No
Remote Gain Function Yes Yes Yes
Distortion at Rated Power < 0.9% THD+N < 0.9% THD+N < 0.9% THD+N
Frequency Response 20Hz to 200Hz 20Hz to 200Hz 20Hz to 200Hz
+0, -1dB +0, -1dB +0, -1dB
Linear Bandwidth 10Hz to 500Hz 10Hz to 500Hz 10Hz to 500Hz
±3dB ±3dB ±3dB
Signal-to-Noise Ratio at > 80dB > 80dB > 80dB
Rated Power
Damping factor > 50 > 50 > 50
Input Sensitivity 200mV to 5V 200mV to 5V 200mV to 5V
Input Impedance 40kW 40kW 40kW
Fuse Type (1) 50 Amp MAXI (3) 40 Amp ATC None
Dimensions 16.4"x10.5"x2.3" 18.7"x10.5"x2.3" 27.2"x10.5"x2.3"
Weight 13 lbs. 16 lbs. 24 lbs.
Crossover Section
Low Pass Crossover Continuously Continuously Continuously
Variable Variable Variable
2nd Order / 2nd Order / 2nd Order /
4th Order 4th Order 4th Order
Low Pass Frequency Range 30Hz to 250Hz 30Hz to 250Hz 30Hz to 250Hz
High Pass Filter Continuously Continuously Continuously
Variable Variable Variable
2nd Order / 2nd Order / 2nd Order /
4th Order 4th Order 4th Order
High Pass Frequency 10Hz to 150Hz 10Hz to 150Hz 10Hz to 150Hz
INTELLi Q 0 - 10dB boost 0 - 10dB boost 0 - 10dB boost
4
©2003 Directed Electronics, Inc.
