2. +BAT - connect this terminal through a FUSE or CIRCUIT BREAKER to the positive
terminal of the vehicle battery or the positive terminal of an isolated audio sys-
tem battery.
WARNING: Always protect this power wire by installing a fuse or circuit breaker of the
appropriate size within 12 inches of the battery terminal connection.
3. REM - this terminal turns on the amplifier when (+) 12 volt is applied. Connect it
to the remote turn on lead of the head unit or signal source. If a (+) 12 volt remote
turn lead is not available, a Remote Power Adapter (P/N #55000) can be used to
supply a remote turn on signal. DO NOT connect this terminal to constant (+) 12
volt.
4. GND - power return connection. Connect this terminal directly to the sheet metal
chassis of the vehicle, using the shortest wire necessary to make this connection.
Always use wire of the same gauge or larger than the (+) 12 volt power wire. The
chassis connection point should be scraped free of paint and dirt. Use only quali-
ty crimped and/or soldered connectors at both ends of this wire. DO NOT connect
this terminal directly to the vehicle battery ground terminal or any other factory
ground points.
5. Speaker - connect the speakers to these terminals. (refer to the Speaker
Connection section of this guide.)
NOTE: Make all connections to power, ground, speakers, and remote terminals before
final positioning and installation of the amplifier in the vehicle.
NOTE: the HCCA-D5000 has two terminal strips for power connections. The +BAT and
GND connections can be made to either of these terminals.
CEA SPECIFICATIONS
HHCCCCAA--DD11220000
Power Output: 250 Watts RMS x 1 at 4 ohms and <
1% THD+N
Signal to Noise Ratio: -60 dBA (reference 1 Watt into 4 ohms)
Additional Power Output: 600 Watts RMS x 1 at 1 ohm at 14.4 Supply<
1% THD+N
HHCCCCAA--DD22440000
Power Output: 450 Watts RMS x 1 at 4 ohms and <
1% THD+N
Signal to Noise Ratio: -60 dBA (reference 1 Watt into 4 ohms)
Additional Power Output: 1200 Watts RMS x 1 at 1 ohm at 14.4 Supply<
1% THD+N
HHCCCCAA--DD55000000
Power Output: 1000 Watts RMS x 1 at 4 ohms and <
1% THD+N
Signal to Noise Ratio: -60 dBA (reference 1 Watt into 4 ohms)
Additional Power Output: 2500 Watts RMS x 1 at 1 ohm at 14.4 Supply<
1% THD+N
