Chapter 1 7
Closed Front View
# Icon Item Description
1 N/A Speakers Left and right speakers deliver stereo audio output.
2 Bluetooth communication
button/indicator
Enables/disables the Bluetooth communication.
Indicates the status of Bluetooth communication (for selected
models).
3 Wireless communication
button/indicator
Enables/disables the wireless function.
Indicates the status of wireless LAN communication.
4 Power indicator Indicates the computer’s power status.
5 Battery indicator Indicates the computer’s battery status.
6 CIR receiver Receives signals from a remote control (for selected
models).
7 Microphone-in jack Accepts input from external microphones.
8 Line-in jack Accepts audio line-in devices (e.g., audio CD player, stereo
walkman).
9 Headphones/speaker/
line-out jack with S/PDIF
support
Connects to audio line-out devices (e.g., speakers,
headphones).
10 N/A Latch Locks and releases the lid.
