4-22 Chapter 4: BIOS setup
Select Screen
Select Item
+-
Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.58 (C)Copyright 1985-2006, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
4.4.5 CPU Conguration
The items in this menu show the CPU-related information that the BIOS
automatically detects.
Modify Ratio Support [Disabled]
Conguration options: [Disabled] [Enabled]
The following item appears when the item Modify Ratio Support is set to
[Enabled].
Ratio CMOS Setting: [24]
Allows you to set the ratio between the CPU Core Clock and the FSB
Frequency. Use <+> and <-> to adjust the value.
Conguration options: [14] [15]~[23] [24]
C1E Support [Enabled]
Allows you to enable or disable C1E Support.
Conguration options: [Enabled] [Disabled]
Max CPUID Value Limit [Disabled]
Setting this item to [Enabled] allows legacy operating systems to boot even without
support for CPUs with extended CPUID functions.
Conguration options: [Disabled] [Enabled]
Vanderpool Technology [Enabled]
Conguration options: [Enabled] [Disabled]
CPU TM function [Enabled]
Conguration options: [Disabled] [Enabled]
Congure advanced CPU settings
Module Version: 3C.0E
Manufacturer: Intel
Brand String: Genuine Intel(R) CPU 3.20GHz
Frequency : 3.20GHz
FSB Speed : 532 MHz
Cache L1 : 16 KB
Cache L2 : 256 KB
Ratio Status: Unlocked (Max:24, Min:14)
Ratio Actual Value : 24
CPUID : F41
Modify Ratio Support [Disabled]
C1E Support [Enabled]
Max CPUID Value Limit: [Disabled]
Vanderpool Technology [Enabled]
CPU TM function: [Enabled]
Execute Disable Bit [Enabled]
Hyper Threading Technology [Enabled]
PECI [Disabled]
Intel(R) SpeedStep(tm) Tech. [Disabled]
Options
Disabled
Enabled
