Woofer Size 6.5 (NOS6) 8 (NOS8, NOS8W, NOS8P)
Voice Coil Size 1 high power. /high temp. 2 high pwr. /high temp.
Magnet Size 20 oz. 36 oz.
Frequency response* 39-1500 hz. 39-1500 hz.
Efficiency* 100 dB* 102 dB*
Power Handling 6-100 watts/channel 6-300 watts/channel
Dimensions 18x6.75x8 27.5" x 8.5" x 10"
Weight 11 lbs. 23 lbs.
Impedance SVC 4 ohm SVC 4 ohm
SYSTEM FEATURES
6 or 8 PURE-PISTON WOOFER
150 WATT HIGH POWER AMP (NOS8A ONLY)
TURBO COOLED VOICE COILS
BASS REFLEX, DUCTED PORT ENCLOSURE
CORNER LOADING
COPLANAR OUTPUT
HIGH OUTPUT EFFICIENCY
MOISTURE RESISTANT ENCLOSURE AND WOOFER
MAXIMIZED SPACE EFFICIENCY
1 YEAR WARRANTY
LARGE MAGNET FOR INCREASED POWER HANDLING
* The efficiency levels of all Bazooka subwoofer speaker systems are measured in the
typical environment: In the low bass region with one watt of power.
3
SPECIFICATIONS: PASSIVE UNITS
SPECIFICATIONS: NOS8A
Woofer Size 8
Voice Coil Size 1.5 high power./high temp.
Magnet Size 28 oz.
Frequency response* 39-250 hz.
Efficiency** 102 dB*
Power Handling 150 watts
Dimensions 18.325" x 8.5" x 10"
Weight 20 lbs.
Impedance 4 ohms
