4-1
Chapter 4
LANVIEW LEDs
The front panel LANVIEW LEDs indicate the status of the module and aid in
troubleshooting the module. The LANVIEW LEDs of the 9A426-02 Module are
shown in Figure 4-1.
Figure 4-1. The LANVIEW LEDs of the 9A426-02 Module
SMB CPU
INB
ATM
9A426-02
FNB
A
T
M
1
A
T
M
2
INB Receive
INB Transmit
FNB Receive
FNB Transmit
System Status
ATM Receive
ATM Transmit
ATM Receive
ATM Transmit
