HSIM-F6 User’s Guide 5-1
CHAPTER 5
SPECIFICATIONS
This chapter lists the operating specifications for the HSIM-F6. Cabletron
Systems reserves the right to change these specifications at any time
without notice.
5.1 FIBER OPTIC INTERFACE
Depending on the FPIM, interfaces have the following characteristics:
5.1.1 Multimode Specifications
Table 5-1 Multimode Transmitter Specifications
Multimode Transmitter
Optical wavelength 1330 nm typical
Optical output
-20.0 dBm minimum
-14.0 dBm maximum
Optical rise time 3.5 ns maximum
Optical fall time 3.5 ns maximum
Spectral width 140 nm typical
Supply current 150 mA maximum
Table 5-2 Multimode Receiver Specifications
Multimode Receiver
Optical wavelength 1330 nm typical
Optical input
(avg. sensitivity)
-31.0 dBm minimum
-14.0 dBm maximum
Output rise time 3 ns maximum
Output fall time 3 ns maximum
Supply current 150 mA maximum
