10
!6
!5
!4
✽
!3
!0
!1 !2
✽ Kensington Security Slot
This slot is for a Kensington lock used to deter
theft of the projector.
* Kensington is a registered trademark of ACCO Brands
Corporation.
Bottom
Back
qAlarm Speaker
wInfrared Remote Receiver
e WIRELESS Indicator
rFocus Lever
t Projection Lens
yZoom Ring
u Slide Shutter
i Top Controls and Indicators
o Air Intake Vent
!0 Exhaust vent
!1 Speaker
!2 Air Intake Vent (back and bottom)
!3 Terminals and Connectors
!4Power Cord Connector
!5SD Card Slot
!6 LAN Connection Terminal
!7 Lamp Cover
!8 Filter
!9 Battery Cover
@0 Adjustable Feet
!7
CAUTION
Hot air is exhausted from the exhaust
vents. Do not put heat-sensitive objects
near this side.
ue r t y
Front
q
w
Part Names and Functions
!8
i o
!9
!2
@0
✔
Note:
e WIRELESS Indicator and !6
LAN Connection Terminal are for
the Network function. Refer to the
owner’s manual “Network Set-up and
Operation”.
CAUTION
Do not turn on a projector with slide
shutter closed. High temperature from
light beam may damage lens cap and
result in fire hazard.
