-38-
3V BACK PORCTH 83 0 ~ 2048
4 DISP LINE 1012 0 ~ 2048
5 CLAMP 7 0 ~ 2048
Group:515 HDTV 720p Gakaku
0 TOTAL DOTS 1524 0 ~ 2048
1 DISP DOTS 1154 0 ~ 2048 720p
2H BACK PORCTH 1098 0 ~ 2048 Stored by SH2, controlled by PW
3V BACK PORCTH 54 0 ~ 2048
4 DISP LINE 702 0 ~ 2048
5 CLAMP 8˜ 0 ~ 2048
Group:516 HDTV 575p Gakaku
0 TOTAL DOTS 1308 0 ~ 2048
1 DISP DOTS 1364 0 ~ 2048 575p
2H BACK PORCTH 937 0 ~ 2048 Stored by SH2, controlled by PW
3V BACK PORCTH 100 0 ~ 2048
4 DISP LINE 536 0 ~ 2048
5 CLAMP 8 0 ~ 2048
Group:517 HDTV 480p Gakaku
0 TOTAL DOTS 1326 0 ~ 2048
1 DISP DOTS 1364 0 ~ 2048 480p (memory 6 top, bottom, left and right)
2H BACK PORCTH 941 0 ~ 2048 Stored by SH2, controlled by PW
3V BACK PORCTH 102 0 ~ 2048
4 DISP LINE 440 0 ~ 2048
5 CLAMP 7 0 ~ 2048
Group:518 RGB NTSC Gakaku
0 TOTAL DOTS 1312 0 ~ 2048
1 DISP DOTS 1024 0 ~ 2048 RGB NTSC
2H BACK PORCTH 224 0 ~ 2048 Stored by SH2, controlled by PW
3V BACK PORCTH 44 0 ~ 2048
4 DISP LINE 457 0 ~ 2048
5 CLAMP 4 0 ~ 2048
Group:519 RGB PAL Gakaku
0 TOTAL DOTS 1348 0 ~ 2048
1 DISP DOTS 1024 0 ~ 2048 RGB PAL
2H BACK PORCTH 258 0 ~ 2048 Stored by SH2, controlled by PW
3V BACK PORCTH 60 0 ~ 2048
4 DISP LINE 536 0 ~ 2048
5 CLAMP 4 0 ~ 2048
Group:520 RGB 1080i-60 Gakaku
0 TOTAL DOTS 1610 0 ~ 2048
1 DISP DOTS 1372 0 ~ 2048 RGB 1080i-60
2H BACK PORCTH 186 0 ~ 2048 Stored by SH2, controlled by PW
3V BACK PORCTH 52 0 ~ 2048
4 DISP LINE 1052 0 ~ 2048
5 CLAMP 7 0 ~ 2048
Group:521 RGB 1080i-50 Gakaku
0 TOTAL DOTS 1934 0 ~ 2048
1 DISP DOTS 1372 0 ~ 2048 RGB 1080i-50
2H BACK PORCTH 188 0 ~ 2048 Stored by SH2, controlled by PW
3V BACK PORCTH 53 0 ~ 2048
4 DISP LINE 1052 0 ~ 2048
5 CLAMP 7 0 ~ 2048
Group:522 RGB 1035i Gakaku
0 TOTAL DOTS 1604 0 ~ 2048
1 DISP DOTS 1366 0 ~ 2048 RGB 1035i
2H BACK PORCTH 186 0 ~ 2048 Stored by SH2, controlled by PW
3V BACK PORCTH 87 0 ~ 2048
4 DISP LINE 1014 0 ~ 2048
5 CLAMP 7 0 ~ 2048
Group:523 SCART 575i Gakaku
0 TOTAL DOTS 1356 0 ~ 2048
1 DISP DOTS 999 0 ~ 2048 SCART 575i
2H BACK PORCTH 523 0 ~ 2048 Stored by SH2, controlled by PW
3V BACK PORCTH 64 0 ~ 2048
4 DISP LINE 518 0 ~ 2048
5 CLAMP 0 0 ~ 2048
Group:524 SCART 480i Gakaku
0 TOTAL DOTS 1308 0 ~ 2048
1 DISP DOTS 999 0 ~ 2048 SCART 480i
2H BACK PORCTH 493 0 ~ 2048 Stored by SH2, controlled by PW
3V BACK PORCTH 49 0 ~ 2048
4 DISP LINE 440 0 ~ 2048
5 CLAMP 0 0 ~ 2048
Group:550 Gakaku Option
0480i H Offset 248 0 ~ 255 H position fine adjustment at component
1575i H Offset 11 0 ~ 255 Stored by SH2, controlled by PW
No. Adjustment Item Initial Value Range Input source / Description
Electrical Adjustments
