<38> ThinConnect4
3.3.7 Options for Serial Port
ThinConnect4 has seven basic connecting functions as listed below:
• ISP Dial-Up IP Connection • ISP Networking Dial-Up IP Connection
• RAS Client Dial-Up IP Connection • Networking Dial-Up IP Connection
• RAS Server IP Connection • ISP Leased Line IP Connection
• Leased Line IP Connection
When using one serial port, you can choose one of eight types of connections below:
• ISP Dial-Up IP Connection • ISP Networking Dial-Up IP Connection
• RAS Client Dial-Up IP Connection • Networking Dial-Up IP Connection
• RAS Server IP Connection • ISP Leased Line IP Connection
• Leased Line IP Connection
• ISP Dial-Up IP Connection + RAS Server IP Connection
• RAS Client Dial-Up IP Connection + RAS Server IP Connection
If you are using both serial ports, you can choose one of possible combination below:
Serial Port 2
ID IDS RC RCS RS IN N ND IL L LD
ID N/A N/A N/A N/A OK N/A OK N/A N/A OK N/A
IDS N/A N/A N/A N/A OK N/A OK N/A N/A OK N/A
RC N/A N/A N/A N/A OK N/A OK N/A N/A OK N/A
RCS N/A N/A N/A N/A OK N/A OK N/A N/A OK N/A
RS OK OK OK OK OK OK OK OK OK OK OK
IN N/A N/A N/A N/A OK N/A OK N/A N/A OK N/A
N OK OK OK OK OK OK OK OK OK OK OK
ND N/A N/A N/A N/A OK N/A OK N/A N/A OK N/A
IL N/A N/A N/A N/A OK N/A OK N/A N/A OK N/A
L OK OK OK OK OK OK OK OK OK OK OK
Serial Port 1
LD N/A N/A N/A N/A OK N/A OK N/A N/A OK N/A
• ID: ISP Dial-Up IP Connection
• IDS: ISP Dial-Up IP Connection + RAS Server IP Connection
• RC: RAS Client Dial-Up IP Connection
• RCS: RAS Client Dial-Up IP Connection + RAS Server IP Connection
• RS: RAS Server IP Connection
• IN: ISP Networking Dial-Up IP Connection
• N: Networking Dial-Up IP Connection (without “default gateway” settings)
• ND: Networking Dial-Up IP Connection (with “default gateway” settings)
• IL: ISP Leased Line IP Connection
• L: Leased Line IP Connection (without “default gateway” settings)
• LD: Leased Line IP Connection (with “default gateway” settings)
• N/A: Not applicable
• OK: The serial port combination is allowed.
