U. Apron.
V. Longitudinal Handwheel:
W. Cross Slide Handwheel:
Note: Direct read means that the distance the
handwheel dial indicates is what is removed
from the diameter of the workpiece. The
cross slide only moves
1
⁄2 that distance.
X. Saddle:
Y. Cross Slide:
Z. Quill Handwheel:
AA. Graduated Dial:
AB. Tailstock Lock Lever:
AC. Quill Lock:
AD. Quill:
AE.Tailstock Offset Screw:
AF. Offset Scale:
Figure 21.
Tailstock Controls
