Specifications 37
Dimensions
The following table lists the dimensions of the FC 16B.
Power Supply
The following table lists the power supply specifications.
Vibration (non-operating) 10 G, 0-5 kHz at 1.0 octave/minute
Condition Acceptable Range
Dimension Value
Height 1U
Depth 24 inches (61.0 cm)
Width 17 inches (43.2 cm)
Weight (with both power supplies installed) 28.5 lbs (12.9 kg)
Specification Value
Total power available from
each power supply
126 Watts, with fans operating
Input voltage 100 - 240 VAC
Input line frequency 47 - 63 Hz
Harmonic distortion Active power factor correction per
IEC1000-3-2
BTU rating 108 Watts x 3.412 BTU/Hr/Watts = 368.5
BTU/Hr
