Security cable lock
NOTE: The security cable lock is included with the base enclosure, spare part number 639569-001.
Before removing the security cable lock, remove the following components:
1. Battery (see
Battery on page 37)
2. Service access cover (see
Service access cover on page 38)
3. Hard drive (see
Hard drive on page 39)
4. Optical drive (see
Optical drive on page 41)
5. Keyboard (see
Keyboard on page 47)
6. Top cover (see
Top cover on page 49)
Remove the security cable lock:
1. Remove the two Phillips 4.0 x 2.5 screws that secure the security lock to the base enclosure.
2. Lift the security lock straight up to remove it from the computer.
Reverse this procedure to install the security cable lock.
Component replacement procedures 57
