1–4 Maintenance and Service Guide
Product Description
■ Connectors:
❏ External monitor port
❏ Universal Serial Bus (USB) v. 2.0 (up to 3 ports)
❏ RJ-11 (modem) jack
❏ RJ-45 (network) jack
❏ Audio-out (headphone) jack
❏ Audio-in (microphone) jack
❏ Power
❏ IEEE 1394 digital port
❏ S-Video-out jack (select models only)
❏ Expansion port 2 (select models only)
❏ 6-in-1 Digital Media Slot (select models only)
❏ 6-in-1 Memory Reader (select models only)
1.2 Resetting the Computer
If the computer you are servicing has an unknown password,
follow these steps to clear the password. These steps also
clear CMOS:
1. Prepare the computer for disassembly (refer to Section 5.3,
“Preparing the Computer for Disassembly,” for more
information).
2. Remove the real-time clock (RTC) battery (refer to
Section 5.14, “RTC Battery,” for more information).
