194
Chapter 6 Configuring the Epson FX-1050 Emulation with Control Codes
Underline
ASCII Code ESC –
n
Hex Code 1B 2D
n
Dec Code 27 45
n
Purpose Turns automatic underlining on and off.
where:
n
= NUL or 0 (hex 00 or hex 30) to turn off underlining
n
= SOH or 1 (hex 01 or hex 31) to turn on underlining
Comment Spaces are underlined, but graphics and grey scale characters
are not.
Example The following sample illustrates underlining.
Unidirectional Printing, 1 Line
ASCII Code ESC <
Hex Code 1B 3C
Dec Code 27 60
Purpose Causes printing to occur from left to right for one line only.
†Comment The printer ignores this command.
Unidirectional Printing, Set/Reset
ASCII Code ESC U
n
Hex Code 1B 55
n
Dec Code 27 85
n
Purpose Causes printing to occur in only one direction of shuttle
movement (left to right).
†Comment The printer ignores this command.
