9
ENGLISH
Camera
Index Button [INDEX] (੬ pg. 26)/
Remaining Space Button/Data Battery
Button [ / ] (੬ pg. 14, 19)
Set Lever
Move to :
Reverse Skip (੬ pg. 24)/Up/Backlight
Compensation [
] (੬ pg. 22)/Spot
Exposure Control [
] (੬ pg. 22)
Move to :
Forward Skip (੬ pg. 24)/Down/
Manual Focus (੬ pg. 21)
Move to :
Reverse Search (੬ pg. 24)/Left/
Nightalive [NIGHT] (੬ pg. 21)
Move to :
Forward Search (੬ pg. 24)/Right/
Change Flash Setting/Change LED Light
Setting [LIGHT/FLASH] (੬ pg. 18)
Press down:
Play/Pause (੬ pg. 24)
Menu Button [MENU] (੬ pg. 46)
Speaker (੬ pg. 24)
Playback/Recording Mode Switching
Button [SELECT PLAY/REC] (੬ pg. 16)
Zoom Lever [W , T
] (੬ pg. 18)
Speaker Volume Control [–VOL+]
(੬ pg. 24)
Still Image Shooting Button [SNAPSHOT]
(੬ pg. 17)
ND Filter Button [ / ] (੬ pg. 19)/
Self Timer Button [ ] (੬ pg. 17)
Program AE Dial (੬ pg. 20)
Function Button [FUNCTION] (੬ pg. 22)
Direct DVD Button [DIRECT DVD]
(੬ pg. 41 and PC OPERATION GUIDE)
Direct Backup Button [DIRECT BACK UP]
(੬ PC OPERATION GUIDE)/Event Button
[EVENT] (੬ pg. 19)
Tele Macro Button [TELE MACRO]
(੬ pg. 16, 17)/Information Button [INFO]
(੬ pg. 32)
Access/Charge Lamp [ACCESS/CHARGE]
(੬ pg. 12)
(Blinks when you access fi les or charge
the battery. Do not turn off the power or
remove the battery pack/AC adapter while
accessing fi les.)
Video/Still Image Mode Lamp [ , ]
(੬ pg. 16, 17)
Video Recording Start/Stop Button [REC]
(੬ pg. 16)
Power/Mode Switch [OFF (CHARGE), ON,
MODE] (੬ pg. 12)
Lock Button (੬ pg. 12)
Flash (੬ pg. 18)
Camera Sensor
Remote Sensor (੬ pg. 7)
LED Light (੬ pg. 18)
Lens Cover (੬ pg. 14)
Lens
Shoe
Microphone Input Connector [PLUG IN
POWER]
USB (Universal Serial Bus) Connector
[
] (੬ pg. 38, 40 and PC OPERATION
GUIDE)
Stereo Microphone
Lens Cover Switch [ , ] (੬ pg. 14)
SD Card Slot (੬ pg. 15)
Stud Hole (੬ pg. 14)
Tripod Mounting Socket (੬ pg. 14)
Battery Release Button [BATT.] (੬ pg. 12)
Battery Pack Mount (੬ pg. 12)
DC Input Connector [DC] (੬ pg. 12)
Audio/Video Connector [AV]
Grip Strap (੬ pg. 14)
Remote Control
Infrared Beam Transmitting Window
ZOOM (T/W) Buttons
Zoom In/Out (੬ pg. 18)
Up Button
Rotate Button (counterclockwise)
(੬ pg. 25)
Skip Backward Button
Left Button
Back Button
PLAYLIST Button (੬ pg. 34)
START/STOP Button
SNAPSHOT Button (੬ pg. 17)
INFO Button (੬ pg. 32)
Skip Forward Button
PLAY/PAUSE Button
Right Button
Next Button
Down Button
Rotate Button (clockwise) (੬ pg. 25)
INDEX Button
DATE Button
