10
Accessories
AC Adapter
AP-V18U/14U
Battery Pack
BN-VF808U
Audio/Video Cable USB Cable
(p. 42, 44, 53 and 60)
Shoulder Strap
(p. 11)
CD-ROM
(p. 52)
Remote Control Unit
RM-V751U (p. 11)
Lithium Battery
CR2025
Pre-installed in the
remote control unit.
NOTE
Make sure to use the provided cables for
connections. Do not use any other cables.
Everio Dock
CU-VC6U (see below)
Core Filter
(Large and small)
(p. 11)
How to Use the Everio Dock
You can connect cables to the connectors of the Everio dock.
The connection is completed when you place the camera on the dock.
NOTE
For the connection using the S-Video jack and DV jack, an optional S-Video cable and DV cable
are needed. Consult the JVC Service Center described on the sheet included in the package for
details on its availability. Make sure to connect the end with a core fi lter to the camera. The core
fi lter reduces interference.
The S-Video cable (optional) enables even higher playback quality on TV. (p. 32)
When dubbing fi les from the camera with a VCR/DVD recorder (p. 48), using the DV cable
enables even higher dubbing quality. Operation using the DV cable is not guaranteed on all
devices.
Camera Connection
Terminal
S-Video Jack
AV Jack
DC Jack
DV Jack
USB Jack
GETTING STARTED
