GETTING STARTED
Thank you for purchasing JD-VD520. Unpack the unit and make sure all the accessories are
put aside so they will not be lost. We recommend that you retain the original carton and
packaging materials for future use, should you transport or ship the unit in the future.
5.1-Channel Progressive-Scan DVD Player with Karaoke Function
• Compatible with NTSC / PAL system
• Progressive- and interlaced-scan video outputs
• Capable of Dolby® Digital decoding
• Coaxial digital audio output
• 5.1-channel audio output
• Supports Karaoke function
• Multiple subtitles and viewing angles
• Slow- and fast-motion playback
• Zoom operation and repeat playback
• Convenient on-screen display (OSD)
• Two built-in microphone jacks
• Playable media: DVD / VCD / Audio CD / CD-R / CD-RW / JPEG CD / Kodak picture CD
In the Box
• DVD Player
• Remote Control
• AV Cable
• Instruction Manual
• Warranty Card
ABOUT DISC ERROR
This compact disc player has built-in error compensation circuits to correct for minor defects in
a disc. There are limits, however, to the amount of correction available. In some cases, the
DVD player may skip some tracks, or parts of tracks, on a disc during disc play. This problem
may be caused by defects (such as scratches) in the disc being played, which are too large for
the error compensation circuits to handle. If you encounter this problem, try a new disc before
having the unit serviced. If the DVD player operates normally, the skipping problem is probably
due to a defective disc.
Note: Only the above types of discs can be played on this unit.
HOME DVD PLAYER V10M10_IM_EN_12312007
www.jWIN.com
9
GETTING STARTED
Location of Controls on the Main Unit
[Front Panel]
1. Disc loader
2. OPEN/CLOSE button
3. STOP/STANDBY button
4. PLAY button
5. STANDBY indicator
6. Remote control sensor
7. LED screen
8. MIC 1
9. MIC 2
[Rear Panel]
1. Power Cord
2. Component Video output (Y, Pb, Pr)
3. Coaxial Digital Audio output
4. 5.1CH Audio output
5. Composite video output
6. S-Video output
Location of Controls on the Remote Control
1. STANDBY
2. CLEAR
3. Numerical Keypad
4. OPEN / CLOSE
5. REV (Reverse)
6. ANGLE
7. UP (S)
8. LEFT (W) / SKIP
BACKWARD
9. SEARCH
10. SUBTITLE
11. TITLE/ RETURN
12. KARAOKE
13. MODE
14. DISPLAY
15. MUTE
16. PAUSE / STEP
17. REPEAT A / B
18. STOP
19. FWD (Forward)
20. ZOOM
21. PLAY/ ENTER
22. RIGHT (X) / SKIP
FORWARD
23. DOWN (T)
24. SETUP
25. DVD MENU/PBC
26. AUDIO
27. VOLUME (+/-)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
