Specifications

7-4

Physical Specifications

Clearance Requirements

Table 7-4: Printer Physical Specifications

Dimension

Printer Model

C510, C510n C510dtn X422

Height 385 mm (15.2 in.) 590 mm (23.2 in.) 539.75 mm (21.25 in.)

Width 495 mm (19.5 in.) 495 mm (19.5 in.) 495.3 mm (19.5 in.)

Depth 420 mm (16.5 in.) 525 mm (20.7 in.) 412.75 mm (16.25 in.)

Weight 31.5 kg (69 lb) 42.4 kg (93 lb) 20.41 kg (45 lb)

Dimension

Printer Model

E23x, E33x

Height 249 mm (9.8 in.)

Width 396 mm (15.6 in.)

Depth 353 mm (13.9 in.)

Weight 9.98 kg (22 lb)

Table 7-5: Clearance Requirement Specifications

Printer Side

Printer Model

C510(n)

1

X422

E230, E232, 234(n),

E330, E332n

Left side 203 mm (8 in.)

1

300mm (12 in.)

Right side 508 mm (20 in.) 76.2 mm (3 in.) 300mm (12 in.)

Front 711 mm (28 in.)

1

200mm (8 in.)

Rear 254 mm (10 in.)

355 mm (14 in.) w duplex

1

50mm (2 in.)

Above 584 mm (23 in.)

635 mm (25 in.) w duplex

736 mm (29 in.) w extra

tray, whether duplex

attached or not

254 mm (10 in.) 150mm (6 in.)

1

When installing the MFP, leave enough room to access the paper

tray(s), the multipurpose feeder, the left side door, and the rear exit

door.
