Outline drawings
4
SPECIFICATIONS
Parameter unit (FR-PU04)
<Outline drawing> <Panel cut dimension drawing>
Choose the mounting screws whose length will not exceed the effective depth of the
mounting threads.
125 (4.92)
5-M3 hole
5- 4 hole
Effective depth 4.5
40 (1.57)
23.75 (0.93)
11.75
(0.46)
81.5 (3.21)
1.25
(0.05)
1.5 (0.06)
17 (0.67)
16.5
(0.65)
1.5
(0.06)
72 (2.83)
15
(0.59)
10.5
(0.41)
18.5 (0.73)
80 (3.15)
48 (1.89)
24
(0.97)
13
(0.51)
20 (0.79)
21.5 (0.85)
14.5 (0.57)
13 (0.51)
40 (1.57)
(Unit:mm (inches))
