371080D-01 Aug08

Table 1 lists the signal connection corresponding to each pin.

Table 1. SCC-AO10 I/O Connector Signal Assignments

Pin Number Signal

1 E/M Series AO (X)

2 E/M Series AO GND

3 —

4 E/M Series AO GND

5 —

6 —

7 —

8 —

9 +5 V

10 GND

11 —

12 + 5 V reference

13 +15 V

14 –15 V

15 —

16 —

17 —

18 —

19 —

20 —
