B1051061 Rev. – USBCam2 User Guide
18
4.4. Acquiring Video Images with the Footpedal
Serial footpedals (Schick P/N B2501100; PDCO P/N 07-0410100) can be used to control
the capture of video images. Refer to the following table for information on using this
footpedal to capture video images.
Table 2. Footpedal Actions
Video Desired Action Use Pedal
Freeze Image Green
Streaming
Close Video Window Amber
(Image is frozen in video window) Take Image Green
Still
(Image is frozen in video window) Unfreeze Image Amber
4.5. Acquiring Video Images with Keyboard Shortcuts
Video image acquisition can be also accomplished though the use of shortcut keys. To use
the following shortcuts, press and hold down the first key (always the Alt key) and then
press the second key (shown after the plus sign) for the appropriate action.
Table 3. Keyboard Shortcuts
Video Desired Action Use Keys
Freeze Image Alt F
Streaming
Close Video Window Alt C
(Image is frozen in video window) Take Image Alt T
Still
(Image is frozen in video window) Unfreeze Image Alt U
