Product
Specification
Page
3
|
8
June
2012
Mena Computers
Wageningselaan 46=D
3903 LA Veenendaal
|
The Netherlands
Tel
.
+31 (0) 318 518720
sales@shuttleshop.nl
w w w . s h u t t l e s h o p . n l
2x USB 3.0
The Shuttle Slim-PC
Barebone
XH61V
sports two
USB
3.0
ports
besides
four
USB
2.0 ports.
USB
3.0
achieves a
maximum
data rate
of up
to
5.0Gbps (640MBytes/sec)
which is ten tim
e
s faster
than
USB
2.0.
USB
3.0
is fully
compatible
to
USB
2.0. At
a glance,
USB
3.0
connectors seem no
different
to
USB
2.0
connectors, however
USB
3.0
connectors have 5
more
pins
placed
inside the
connector
its
e
lf.
USB
2.0
can provide
a
maximum
of 500mA to the
USB
device
whil
e
USB
3.0
can provide
a
maximum output
of 900mA, which is
important
for
portable hard
drives.
USB
3.0 also
comes
with
better power saving features
to let y
o
ur
devices
run
more
efficiently when
i
n
idle
m
o
de.
Dual Gigabit LAN Network
Today’s
media-rich communications across
the
i
nternet
and
within
enterprises create
new
demands
for
c
lie
nts
in Local Area Networks. For
that
reason,
Shuttle
applies Gigabit
LAN
performance
to their
M
i
n
i
-PCs
and
XH61V
even supports
two of
them.
Dual
networking
allows
the
computer
to
connect
to
a
single network using two
cables at once
with
an appropriate
switch
(teaming mode
with
load balancing
or
failover
function) or to two
different
networks
depending
on the
needs
of
the
user.
Dual View Technology with HDMI and DVI (or VGA)
Dual View
technology
offers multiple
display support
on up to
two
separate
monitors.
This
helps to
improve
on
productivity by allowing
for
spreading
multiple windows
across
two monitors
whi
l
e
working
w
i
th
them simultaneously.
XH61V
features
two
video outputs:
HDM
I
and
DVI-
I.
DVI-I
HDMI
D-Sub
(VGA)
DVI-D
Video outputs
W
i
th
optional adapters
DVI-D
devices can be connected
to the
HDM
I
port or
VGA
devices
to the
DVI-I
port,
resp
ectively.
DVI-D
means the connector
only
outputs
digital
video
signals.
DVI-
I
means
digital
and analog video
signals
are
put
out.
HDMI
supports
digital
video
plus
multi-chan
n
e
l
digital
audio
output.
Digital
Audio 1
Digital
Audio 2
Analog
Audio 1
Digital Audio
Beside the
analog audio,
XH61V
can provide
digital
multichan
n
e
l
audio
in two
w
a
ys: via the
optical
S/PDIF
output
(Toslink)
or
through
HDMI.
Therefore,
two
audio devices are
shown
i
n
the Windows
device
manager. Connect
the
HDMI
to your
TV
set
and
you
will
have
both
digital
audio and video.
For
better audio expierience
you may use
a
n
audio receiver
(amplifier) with
a bunch
of
speakers around
which is
probably connected
via
S/PDIF. XH61V
is flexible
enough
to
support
both
options.
Two serial ports
M
a
ny
PCs do not
have these legacy
ports
any longer, since
they
have
been superseded and replaced
by
USB
for most
consumer
appli-
cations,
but they
are
still
common
l
y
used
for
applications
such
as
industrial
automation
systems, scientific
analysis,
POS systems
and
other industrial
applications.
XH61V
features
two serial RS-232
ports
