Connectors F-5
F
Figure F-6 CPU Module 0 Connector (288 Pin) Location
Figure F-7 CPU Module 1 Connector (288 Pin) Location
F.2 I/O Board
Figure F-8 and Figure F-9 show the locations of the connectors on the SBus I/O
and Graphics I/O boards.
