Note:
To ensure the BigPond connection re-established normally, please restart the connection at least 5
seconds after the connection is off.
3.1.4 LAN
3.1.4.1 LAN
On this page, you can configure the parameters for LAN port of this router.
Choose the menu Network→LAN→LAN to load the following page.
Figure 3-12 LAN
The following items are displayed on this screen:
LAN
IP Address:
Enter the LAN IP address of the router. 192.168.0.1 is the default IP
address. The Hosts in LAN can access the router via this IP address.
It can be changed according to your network.
Subnet Mask:
Enter the Subnet Mask. The default subnet mask is 255.255.255.0.
Note:
If the LAN IP address is changed, you must use the new IP address to log into the router. To guarantee
a normal communication, be sure to set the Gateway address and the Subnet Mask of the Hosts on
the LAN to the new LAN IP address and the Subnet Mask of the router.
3.1.4.2 DHCP
The router with its DHCP (Dynamic Host Configuration Protocol) server enabled can automatically
assign an IP address to the computers in the local area network.
Choose the menu Network→LAN→DHCP to load the following page.
-28-
