ViewSonic CD5230 38
Specifications
Product Specifications
Note: Specifications and functions of this monitor are subject to change without prior notice.
Product specifications Analog Input Digital Input
LCD Module Diagonal: 52" / 132.08 cm
Pixel Pitch: 0.6 mm
Resolution: 1920 x 1080 dots
Color: Over 16 million colors (depending on video card used)
Brightness:
700 cd/m
2
(typ.)
Contrast Ratio: 4000:1 (typ.)
Response time: 5 ms (typ. G to G)
View Angle:
Up and Down 178 , Left and Right 178 (typ.) @CR>10
Frequency Horizontal: 31 - 70 KHz
Vertical: 50 - 75 Hz
Pixel Clock 25.2 - 85 MHz 25.2 - 148.5 MHz
Viewable Size 1152 x 648 mm / 45.4 x 25.5 inches
Input Signal
PC Input: VGA 15 Pin Mini D-sub
DVI DVI-D
VIDEO Input: HDMI HDMI with HDCP
Y Pb Pr Y Pb Pr (RCA jacks)
AV Composite Video (BNC jacks)
S-Video Y/C (Mini-DIN jack)
AUDIO Input L/R (RCA jacks)
L/R (3.5mm Mini-jack)
RS-232C 9 Pin Mini D-sub
Output Signal
PC-Output: VGA 15 Pin Mini D-sub
DVI DVI-D
VIDEO Output: Y Pb Pr Y Pb Pr (RCA jacks)
AV Composite Video (BNC jacks)
S-Video Y/C (Mini-DIN jack)
Speaker Output: External Speaker Jack 6 W + 6 W (8 ohm)
RS-232C: 9 Pin Mini D-sub
Y Pb Pr Resolutions Supported NTSC,PAL,SECAM,4.43NTSC,PAL60
480i@60, 576i@50, 480p@60, 576p@50, 1080i@60, 1080i@50, 720p@60,
720p@50, 1080p@60, 1080p@50
Power Supply 100 - 240 V AC, 50 / 60 Hz
Power Consumption Max. 350 W
Power Save: Less than 2 W (Standby)
Operational
Environment
Temperature:
Landscape: 0 - 40 C / 32-104 F, Portrait: 5 - 35 C / 41-95 F
Humidity: 20 - 80% (Without condensation)
Storage Environment Temperature:
-20 - 60 C / -4 - 140 F
Humidity: 10 - 90% (Without condensation)
Dimension Net without stand: 1197.4 mm (W) x 693.4 mm (H) x 127.5 mm (D) / 47.1" (W) x 27.3" (H) x 5.0" (D)
Net with stand: 1197.4 mm (W) x 739.7 mm (H) x 223 mm (D) / 47.1" (W) x 29.1" (H) x 8.8" (D)
Weight Net without stand: 83.8 lbs / 38 kg (Approximately)
Net with stand: 90.4 lbs / 41 kg (Approximately) (Stand is optional accessory)
Gross: 99.2 lbs / 45 kg
Wall mounting interface 4 Holes (400mm x 200mm)
Complied Regulatory and Guidelines FCC, ICES003, UL/cUL
Power Management VESA DPM
Plug & Play VESA DDC2B, DDC/CI
