Alpine cda-7840 Car Stereo System User Manual



67
English
Specifications
FM TUNER SECTION
Tuning Range .................................................................
87.7 – 107.9 MHz
Mono Usable Sensitivity ................................. 9.3 dBf (0.8 µV/75 ohms)
50 dB Quieting Sensitivity ..................................
13.5 dBf (1.3 µV/75 ohms)
Alternative Channel Selectivity .........................................................
80 dB
Signal-to-Noise Ratio..................................................................... 65 dB
Stereo Separation .......................................................................... 35 dB
AM TUNER SECTION
Tuning Range ............................................................... 530 – 1,710 kHz
Sensitivity (IEC Standard) ................................................ 22.5 µV/27 dB
CD SECTION
Frequency Response........................................... 5 – 20,000 Hz (±1 dB)
Wow & Flutter (% WRMS) ................................Below measurable limits
Total Harmonic Distortion ...........................................0.008% (at 1 kHz)
Dynamic Range ............................................................ 95 dB (at 1 kHz)
Signal-to-Noise Ratio................................................................... 105 dB
Channel Separation ...................................................... 85 dB (at 1 kHz)
REMOTE CONTROL
Battery Type ........................................................ AAA batteries (2 pcs.)
REMOTE CONTROL SIZE
Width............................................................................... 56 mm (2-1/4")
Height............................................................................... 14 mm (9/16")
Depth ............................................................................ 105 mm (4-1/8")
Weight................................................................................. 50 g (1.8 oz)
GENERAL
Power Requirement ............................... 14.4 V DC (11–16 V allowable)
Maximum Power Output ........................................................... 40 W × 4
Maximum Pre-Output Voltage ..........................................4 V/10 k ohms
Bass .................................................................................. ±15 dB/60 Hz
Treble.............................................................................. ±10 dB/10 kHz
Weight........................................................................1.5 kg (3 lbs. 4 oz)
CHASSIS SIZE (W × H × D)...178 mm (7") × 50 mm (2") × 153 mm (6")
NOSEPIECE SIZE
(W × H × D) ... 170 mm (6-3/4") × 46 mm (1-13/16") × 18 mm (11/16")
Note: Due to continuous product improvement,
specifications and design are subject to
change without notice.
