19-EN
You can flexibly customize the unit to suit your own preferences and
usage. From the SETUP menu, General Setting, Display Setting, etc.,
can be modified.
1
Press and hold F/SETUP for at least 2 seconds to
activate the SETUP selection mode.
2
Turn the Rotary encoder to select the desired item,
and then press
/ENT.
Bluetooth
*
1
General Display XM
*
2
/SIRIUS
*
3
HD Radio
*
4
Bluetooth
(e.g. Select General)
*
1
Displayed only when INT Mute is OFF and the mode is set to other
than Bluetooth Audio.
*
2
Only when XM Radio is connected. For the XM Radio setting, refer to
“SAT Radio Receiver (Optional)” (page 22).
*
3
Only when SIRIUS Radio is connected. For the XM Radio setting,
refer to
“SAT Radio Receiver (Optional)” (page 22).
*
4
Only when HD Radio is connected.
3
Turn the Rotary encoder to select a setting item,
and then press
/ENT.
(e.g. Select AUX IN)
Bluetooth:
Bluetooth IN
General:
Birthday Set Clock Mode Clock Adjust
*
5
Calendar
Play Mode Beep INT Mute
*
6
AUX+ Setup
AUX+ Name
*
7
AUX IN GAIN
*
7
Digital AUX
D.AUX Name
*
8
AUX IN AUX Name
*
9
Changer Name Power IC Language Set Demo
Birthday Set
Display:
Dimmer Dimmer Level Scroll Type Text Scroll
Font Select BGV Select Opening MSG Dimmer
XM:
XM ADF
SIRIUS:
Game Alert
HD Radio:
Station Call Digital Seek Station Call
*
5
Refer to “Setting the Time and Calendar” (page 8).
*
6
Displayed only when Bluetooth IN is OFF.
*
7
Displayed only when AUX+ is ON.
*
8
Displayed only when Digital AUX is ON.
*
9
Displayed only when AUX IN is ON.
4
Turn the Rotary encoder to change the setting,
and then press
/ENT.
(e.g. Select AUX IN ON or AUX IN OFF)
5
Press and hold F/SETUP for at least 2 seconds to
return to normal mode.
• Pressing /ESC returns to the previous SETUP mode.
• If no operation is performed for 60 seconds, SETUP is canceled.
Select Bluetooth from the setup main menu in step2 above.
If an optional Bluetooth Box is connected, you can place a hands-free
call by a Bluetooth- equipped mobile phone.
Make this setting when the Bluetooth Box is connected and the
Bluetooth function is used. For details, refer to the Owner’s Manual of
the optional Bluetooth Box.
Setting the Bluetooth IN Connection
Set ADAPTER when the Bluetooth Box is connected.
• If the Bluetooth Box compatible with the Voice Dial function is
connected, the Voice Dial function can be used.
General is selected on the setup main menu in step 2.
Birthday Opening Message Setting (Birthday Set)
By inputting your birthday details, a message can be displayed on that
day. Turn the Rotary encoder to set “mm” (Month), and then press
/ENT. Turn the Rotary encoder again to set “dd” (Date).
Setting the Clock Display (Clock Mode)
You can select the clock display type, 12-hour or 24-hour, depending on
your preference.
Setting of Calendar Display Pattern Switching (Calendar)
You can switch the calendar display pattern to be shown when the time
is displayed.
ex. dd/mm/yyyy 25/12/2007
Playing MP3/WMA/AAC Data (Play Mode)
This unit can play back CDs containing both CD and MP3 /WMA/AAC
data (created in Enhanced CD (CD Extra) format). However, in some
situations, playback of an enhanced CD may be difficult. In this case,
you can select playback of a single session only, containing the CD data.
When a disc contains both CD and MP3/WMA/AAC data, playback
starts from the CD data portion of the disc.
• Perform this setting before inserting a disc. If a disc has already been
inserted, remove it first. (If you use an MP3 changer, you have to
change discs.)
SETUP
Use steps 1 to 5 to select one of the SETUP modes to
modify. See the applicable section below for details
about the selected SETUP item.
Rotary encoder
SOURCE/
F/SETUP
BAND
/ENT
/ESC
Bluetooth Setting
Bluetooth IN ADAPTER / Bluetooth IN OFF (Initial Setting)
General Setting
mm/dd
AM (Before noon) 12:00 (12-hour) (Initial setting) / 00:00 (24-hour)
dd/mm/yyyy / yyyy/mm/dd / mm/dd/yyyy (Initial setting)
yyyy : shows the year
mm : shows the month
dd : shows the day
CD-DA (Initial setting) / CDDA&MP3/WMA
CD-DA: Only the CD data in Session 1 can be played
back.
CDDA&MP3/WMA:
CD data, MP3/WMA/AAC files in mixed mode,
and multi-session discs can be played back.
