30-EN
Adjusting Subwoofer Level/Bass Level/
Treble Level/Fader (Between Front and
Rear)/Balance (Between Left and Right)/
Black Out in MultEQ mode
You can change these settings to create your own preference in MultEQ
(Curve 1 or Curve 2) mode.
1
Press IMPRINT to activate the MultEQ adjustment
mode.
2
Turn the Rotary encoder to select the desired item,
and then press
/ENT.
SUBW. Level*
1
Bass Level Treble Level Fader*
2
Balance Black Out*
3
SUBW. Level
3
Turn the Rotary encoder to change the setting as
below, and then press
/ENT.
Subwoofer level: 0 ~ +15
Bass level: -7~+7
Treble level: -7~+7
Fader: R15 ~ F15
Balance: L15 ~ R15
Black Out: ON/OFF
• If no operation is performed for 60 seconds after selecting the
SUBW. Level, Bass Level, Treble Level, Fader, Balance or Black Out
mode, the unit automatically returns to normal mode.
*
1
When the subwoofer mode is set to OFF, its level cannot be adjusted,
and the subwoofer ON/OFF cannot be adjusted in MultEQ (Curve 1
or Curve 2) mode.
*
2
If you set the 2.2ch (3WAY)/4.2ch (FRONT/REAR/SUBW.) switch of
the IMPRINT audio processor (PXA-H100) to 2.2ch (3WAY), you
cannot adjust the FADER mode. For details, refer to the Owner’s
Manual of PXA-H100.
*
3
When Blackout mode is turned on, all display indications on this unit
will turn off to reduce power consumption. This additional power
enhances the sound quality.
If any button on the unit is pressed during the blackout mode, the
function will be displayed for 5 seconds to show the operation before
returning to Blackout mode.
• Depending on the connected devices, some functions and display
indications do not work.
Adjusting Sound Setting in Manual Mode
You can change these sound settings to create your own preference
when the MultEQ mode is set to MultEQ off (Manual Mode).
1
Press IMPRINT to activate the Sound menu
selection mode.
2
Turn the Rotary encoder to select the desired item,
and then press
/ENT.
Subwoofer SUBW. System
*
1
SUBW. Phase
*
1
SUBW. Channel
*
1
Factory’s EQ TW Setup
*
2
Filter Type Media Xpander MX Level
*
3
EQ Mode
TCR Parameter Sound Field
*
4
Black Out Subwoofer
(e.g. Select Subwoofer)
*
1
These functions are inoperable when Subwoofer is set to OFF.
*
2
This function can be operable only when PXA-H100 (sold
separately) is connected and 2.2ch (3WAY) mode is set. For details,
refer to the Owner’s Manual of PXA-H100.
*
3
This function is inoperable when Media Xpander is set to OFF.
*
4
In step 2, three sound adjustment items (Parametric EQ/Graphic EQ,
T.Correction, X-Over) can be selected in Sound Field Adjustment
mode, turn the Rotary encoder to select the desired item, and then
press
/ENT to continue to step 3.
3
Turn the Rotary encoder to change the setting,
and then press
/ENT.
(e.g. Select Subwoofer ON or Subwoofer OFF)
4
Press and hold /ESC for at least 2 seconds to
return to normal mode.
• Media Xpander, Factory’s EQ, Parametric EQ/Graphic EQ
Adjustment, EQ Mode and MX Level Adjustment are inoperable
when Defeat is set to ON.
• Pressing /ESC returns to the previous Sound menu mode.
• If no operation is performed for 60 seconds, Sound menu mode is
canceled.
When the subwoofer is on, you can adjust the subwoofer output level
(refer to
page 14).
OFF ON (Initial setting)
When the subwoofer is on, you can select either System1 or System2
for the desired subwoofer effect.
1 (Initial setting) 2
PHASE 0° (Initial setting) PHASE 180°
The subwoofer output phase is toggled SUBWOOFER NORMAL (0°)
or SUBWOOFER REVERSE (180°). To adjust the level, turn the
Rotary encoder.
Use steps 1 to 4 to select one of the Sound menu
modes to modify. See the applicable section below for
details about the selected item.
Turning Subwoofer ON/OFF
Setting the Subwoofer System
System 1 : Subwoofer level changes according to the main
volume setting.
System 2 : Subwoofer level change is different from the main
volume setting. For example, even at low volume
settings, the subwoofer is still audible.
Setting the Subwoofer Phase
