Alpine CDE-9881 Car Stereo System User Manual



15-EN
You can flexibly customize the unit to suit your own preferences and
usage. From the SETUP menu, Sound Customizing, Visual
Customizing, etc., can be modified.
1
Press SETUP to activate the SETUP mode.
2
Turn the Rotary encoder to select the desired
SETUP menu, and then press / /ENT.
(e.g. Select SUBWOOFER)
CLOCK ADJUST*
1
LCD CONTRAST DIMMER
SUBWOOFER (SUBW. SYSTEM) *
2
PLAY MODE SCROLL TYPE TEXT SCROLL
POWER IC LANGUAGE DEMO CLOCK ADJUST
*
1
Refer to “Setting Time” (page 7).
*
2
Displayed only when SUBW is on.
3
Turn the Rotary encoder to change the setting.
(e.g. Select SUBW. ON or SUBW. OFF.)
4
Press SETUP to return to normal mode.
Press RTN to return to the previous mode.
If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
Subwoofer On and Off
When the subwoofer is on, perform the steps below to adjust the
subwoofer output level.
1 In the normal mode, press Rotary encoder repeatedly to
select the SUBW mode.
2 Adjust the level by turning the Rotary encoder.
Setting the Subwoofer System
Select either SYS 1 or SYS 2 for the desired subwoofer effect.
Dimmer Control
Set the DIMMER control to AUTO to decrease the illumination
brightness of the unit with the head lights of the vehicle ON. This mode
is useful if you feel the unit’s backlighting is too bright at night.
Scroll Type Setting
Choose from two scrolling methods.
Select the type you prefer.
Scroll Setting (TEXT SCROLL)
This CD player can scroll the disc and track names recorded on
CD-TEXT discs, as well as the text information of MP3/WMA/AAC
files, folder names and tags.
The unit scrolls CD text names, folder names, file names or tag
display.
SETUP
Use steps 1 to 4 to select one of the SETUP modes to
modify. See the applicable section below for details
about the selected SETUP item.
Sound Customizing
SUBW. ON (Initial setting) / SUBW. OFF
SUBW BASS TREBLE BALANCE FADER
DEFEAT VOLUME SUBW
Rotary encoder
//ENT
RTN SETUP
SUBW. SYS 1 (Initial setting) / SUBW. SYS 2
SUBW. SYS 1:Subwoofer level changes according to the main
volume setting.
SUBW. SYS 2:Subwoofer level change is different from the main
volume setting. For example, even at low volume
settings, the subwoofer is still audible.
Visual Customizing
DIMMER AUTO (Initial setting) / DIMMER MANU
SCROLL TYPE1 / SCROLL TYPE2 (Initial setting)
SCROLL TYPE1: The characters scroll from right to left, a
single character at a time.
SCROLL TYPE2: Words are built up from left to right, a single
character at a time. When the display is filled,
it is cleared and the remaining words are
displayed the same way until all words of the
title have been shown.
SCROLL AUTO / SCROLL MANU (Initial setting)
SCROLL AUTO: The CD text information, the text information of
folder and file names, and the tags are
scrolled automatically.
SCROLL MANU: The display is scrolled when a disc is loaded
or when a track is changed, etc.
