High Level inputs have been included to connect the amplifier to a radio without low-level
outputs (i.e. factory radio). This connection will allow you to connect directly to the
speaker output of the radio with out the need of an external adapter.
Determine the type of radio you have and make one of the following connections.
HIGH LEVEL CONNECTIONS (OPTIONAL)
CAUTION! Before making any connections determine the type of radio to avoid possible
damage to amplifier and/or radio.
TWO CHANNEL CONNECTIONS:
FLOATING GROUND RADIO (MOST COMMON TYPE)
POWER
BASS
BOOST
X-OVER
RIGHT +RIGHT +
RIGHT -RIGHT -
LEFT -LEFT -
LEFT +LEFT +
GREENGREEN
GREEN/BLACKGREEN/BLACK
(NOT USED)(NOT USED)
GRAY/BLACKGRAY/BLACK
BLACKBLACK
GRAYGRAY
94.794.7
GREENGREEN
BLACKBLACK
GRAY/BLACK NOT USEDGRAY/BLACK NOT USED
GREEN/BLACK NOT USEDGREEN/BLACK NOT USED
GRAYGRAY
RIGHT +RIGHT +
LEFT +LEFT +
GROUNDGROUND
94.794.7
TWO CHANNEL CONNECTIONS:
COMMON GROUND RADIO
