SPECIFICATIONS
GENERAL SPECIFICATIONS
................................................................................................................................................
AC Power Requirements 117 or 234 VAC @ 50 or 60 Hz
................................................................................................................................................
Consumption 75 Watts – Operation, 25 Watts - Standby
................................................................................................................................................
Warm-Up Time 3 Minutes
................................................................................................................................................
Break-In Time 100 Hours of Playing Time
................................................................................................................................................
Chassis Finish Silver Anodized Aluminum Faceplate Std, Black Optional
Jaguar® Anthracite Black Finish on Chassis
................................................................................................................................................
Net Weight 16 lbs. – Preamplifier
19 lbs. – External Power Supply
................................................................................................................................................
Dimensions 6.25” H x 17” W x 12” D – Preamplifier
4.5” H x 17” W x 12” D – Power Supply
About 10.5” H Stacked Together
FEATURES
Features of the SLP 05 include:
•
Fully Balanced Design
•
Motorized remote volume control and muting
•
One (1) Cinema Bypass
•
One (1) tape monitor loop (RCA Connections)
•
Two (2) XLR balanced stereo inputs
•
Three (3) RCA stereo inputs
•
One (1) XLR balanced preamplifier output
•
One (1) RCA preamplifier output
The matching ‘chassis size’ external power supply comes with 5AR4 vacuum tube voltage
rectification and has two front panel meters for the circuit voltage and the current bias readings.
The SLP 05 has a timer warm up circuit that allows safe use with “rapid turn on” solid state
power amplifiers. The headphone power amplifier, using two 6SN7 octal vacuum tubes, is
coupled through audio transformers to produce 1/2 watt per channel to drive your favorite high
quality headphones.
8
