APX2121
Maximum power output
Continuous rated power *
Typical power in bridged mode **
Typical power in 2-Ohm load **
IM distortion
S/N (A-weighted)
Floor noise
Channel separation
Frequency response
Line level input sensitivity
Speaker level input sensitivity
Input impedance
Allowable battery voltage
Size
200W
60W x 2
100W x 1
80W x 2
0.1%
72dB
A / N
60dB
20-20kHz full range
200mV to 5.5 Volts
2V to 9 Volts
22K Ohm
9.6 to 15.6 Volts
7 1/8”x11”x2 1/4”
* THD 0.1%, 10Hz-20kHz, into 4-Ohms, @ 14.4V, all channels driven
** THD 0.1%, 10Hz-20kHz, @ 14.4V, all channels driven
APX1301
Maximum power output
Continuous rated power *
Typical power in bridged mode **
Typical power in 2-Ohm load **
IM distortion
S/N (A-weighted)
Floor noise
Channel separation
Frequency response
Line level input sensitivity
Speaker level input sensitivity
Input impedance
Allowable battery voltage
Size
420W
300W x 1
N/A
400W x 1
0.1%
70dB
A/N
A/N
20-20kHz full range
200mV to 5.5 Volts
2V to 9 Volts
22K Ohm
9.6 to 15.6 Volts
11 7/8” x 11” x 2 1/4”
* THD 0.1%, 10Hz-20kHz, into 4-Ohms, @ 14.4V, all channels driven
** THD 0.1%, 10Hz-20kHz, @ 14.4V, all channels driven
