280-8143-00
DXZ555MP 13
English
Adjusting the Z-Enhancer Plus
1. Press the [Z+] button and select the Z-
Enhancer Plus mode to adjust.
2. Press the [A-M] button and turning the
[ROTARY] knob clockwise adjusts in the +
direction; turning it counterclockwise adjusts
in the – direction.
●When “B-BOOST 0” selected, you can
adjust the bass in the range of –3 to 3.
●When “IMPACT 0” selected, you can
adjust the bass and treble in the range of
–3 to 3.
●When “EXCITE 0” selected, you can adjust
the bass and treble in the range of –3 to 3.
∗ When Z-Enhancer Plus is selected, press and
hold the [Z+] button for 1 second or longer to
change to the “CUSTOM” mode.
Bass/treble characteristics become flat and the
indication “Z+ FLAT” is shown in the display.
Adjusting the tone
Press the [A-M] button and select the item to
adjust. Each time you press the [A-M] button,
the item changes as following order:
●When “BASS BOOST” is set
“B-BOOST 0” ➜ “BAL 0” ➜ “FAD 0” ➜
Last function mode.
●When “IMPACT” is set
“IMPACT 0” ➜ “BAL 0” ➜ “FAD 0” ➜ Last
function mode.
●When “EXCITE” is set
“EXCITE 0” ➜ “BAL 0” ➜ “FAD 0” ➜ Last
function mode.
●When “CUSTOM” is set
“BASS <G 0>” ➜ “TREB <G 0>” ➜ “BAL 0”
➜ “FAD 0” ➜ Last function mode.
●When “Z+ OFF” is set
“BAL 0” ➜ “FAD 0” ➜ Last function mode.
Adjusting the bass (Gain,
Frequency, Q-curve)
This adjustment can be performed when the Z-
Enhancer Plus is set to “CUSTOM”.
1. Press the [A-M] button and select “BASS
<G 0>”.
2. Turning the [ROTARY] knob clockwise
emphasizes the bass; turning it
counterclockwise attenuates the bass.
∗ The factory default setting is “
BASS
<G 0>”.
(Adjustment range: –6 to +8)
3. Press the [a, d] lever upward or
downward to select “
BASS
<F 50>”.
Turn the [ROTARY] knob to select the
frequency.
∗ The factory default setting is “
BASS
<F 50>”.
(Adjustment 50/80/120 Hz)
4. Press the [a, d] lever upward or
downward to select “BASS <Q 1>”.
Turn the [ROTARY] knob to select the Q-
curve.
∗ The factory default setting is “
BASS
<Q 1>”.
(Adjustment 1/1.25/1.5/2)
5. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the treble (Gain,
Frequency)
This adjustment can be performed when the Z-
Enhancer Plus is set to “CUSTOM”.
1.
Press the [A-M] button and select “TREB
<G 0>”.
2. Turning the [ROTARY] knob clockwise
emphasizes the treble; turning it
counterclockwise attenuates the treble.
∗ The factory default setting is “
TREB <G 0>
”.
(Adjustment range: –6 to +6)
3. Press the [a, d] lever upward or
downward to select “TREB <F 12K>”.
Turning the [ROTARY] knob to select the
frequency.
∗ The factory default setting is “
TREB <F 12K>
”.
(Adjustment 8 kHz/12 kHz)
4. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the balance
1. Press the [A-M] button and select “BAL 0”.
2. Turning the [ROTARY] knob clockwise
emphasizes the sound from the right
speaker; turning it counterclockwise
emphasizes the sound from the left speaker.
∗ The factory default setting is “BAL 0”.
(Adjustment range: L13 to R13)
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Basic Operations
