8. Specifications
Note:
The technical data and the design of the equipment may change
without prior notice for the sake of technical improvements.
APX Amplifiers
Parameter APX4360 APX2180
Maximum power output 160W x 4 160W x 2
Continuous rated power 90W x 4 90W x 2
Typical power in bridged mode 300W x 2 300W x 1
Typical power in 2-Ohm load 160W x 4 150W x 2
THD (1KHz, 10W, 40 Ohms) ≤ 0.025% ≤ 0.025%
IM distortion ≤ 0.08% ≤ 0.08%
S/N (A-weighted) ≥ 92dB ≥ 93dB
Floor noise ≤ 2mV ≤ 2mV
Channel separation ≥ 70dB ≥ 70dB
Frequency response 10Hz to 50kHz 10Hz to 50kHz
Line level input sensitivity 200mV to 8 Volts 200mV to 8 Volts
Speaker level input sensitivity 600mV to 20 Volts 600mV to 20 Volts
Input impedance 33K Ohms 33K Ohms
Allowable battery voltage 10.5 to 16.5 Volts 10.8 to 16.5 Volts
Size 16"x12"x2 7/8" 12"x12"x2 7/8"
These specifications are Amplifier Power Standard CEA-2006 Compliant.
