Max 30°
Figure 2
Chassis Chassis
Damage
Max.6mm(M5screw)
Figure 3
Hole
73/16″
(182mm)
21/8″
53 mm
26
4) Cautions on Installation
1. Prepare all articles necessary for
installingthesourceunitbefore
starting.
2.Installtheunitwithin30°ofhorizontal.
(Figure2)
3.Ifyouhavetodoanyworkonthecar
body,suchasdrillingholes,consult
yourcardealerbeforehand.
4.Usetheenclosedscrewsfor
installation.Usingotherscrewscan
causedamage.(Figure3)
5) Installing the Source Unit
1.Placethemountingbracketintotheinstrumentpanel,useascrewdrivertobend
eachstopperoftheuniversalmountingbracketinward,thensecurethestopper.
2.WireasshowninSection7.
3.Insertthesourceunitintothemountingbracketuntilitlocks.
4.Carefullyadjustallmountingtabsonthemountingbracketandconrmthatthe
mountingtabsaresecurelyattached.
Notes:
1.Somecarmodelsrequirespecialmountingkitsforproperinstallation.
Consult your Clarion dealer for details.
2. Fasten the front stopper securely to prevent the source unit from coming loose.
• Console opening dimensions
